# How To Compute Average True Range (ATR) In SQL?

To compute the Average True Range (ATR) in SQL, you can follow these steps:

1. Calculate the true range for each day by finding the maximum of the following: High - Low Absolute value of High - Close(previous day) Absolute value of Low - Close(previous day)
2. To calculate the initial ATR value, you can use a simple moving average calculation with a specified period, such as 14 days.
3. Update the ATR value for each subsequent day by using the following formula: ATR = [(Prior ATR x 13) + Current True Range] / 14
4. Repeat this process for each day in your dataset to calculate the ATR value for each day.

By following these steps and using SQL queries to perform the necessary calculations, you can compute the Average True Range (ATR) for a given dataset.

## Best Trading Websites in July 2024

1

Rating is 5 out of 5

Yahoo Finance

2

Rating is 5 out of 5

3

Rating is 4.9 out of 5

FinViz

4

Rating is 4.9 out of 5

FinQuota

## How to automate the calculation of ATR in SQL?

To automate the calculation of Average True Range (ATR) in SQL, you can create a stored procedure or a user-defined function that calculates the ATR based on the historical data stored in a table. Here is an example of how you can create a user-defined function in SQL Server to calculate the ATR:

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 ``` ```CREATE FUNCTION CalculateATR (@Symbol varchar(50)) RETURNS DECIMAL(18,2) AS BEGIN DECLARE @TR DECIMAL(18,2) DECLARE @ATR DECIMAL(18,2) SELECT TOP 1 @TR = MAX(High - Low), @ATR = AverageTrueRange FROM ( SELECT TOP 14 High, Low, ABS(High - LAG(Close, 1) OVER (ORDER BY Date)) AS TR FROM StockData WHERE Symbol = @Symbol ORDER BY Date DESC ) AS Last14Days ORDER BY Date ASC IF @ATR IS NULL SET @ATR = @TR ELSE SET @ATR = ((@ATR * 13) + @TR) / 14 RETURN @ATR END ```

In this function:

1. Replace StockData with the name of your historical data table.
2. Replace the column names (High, Low, Close, Date, Symbol) with the actual column names in your table.
3. The function calculates the True Range (TR) for each day and then calculates the ATR based on the TR values of the past 14 days.
4. The function returns the calculated ATR for the given symbol.

You can then call this function in your SQL queries to get the ATR values for each symbol. For example:

 ```1 2 3 4 ``` ```SELECT Symbol, Date, High, Low, Close, dbo.CalculateATR(Symbol) AS ATR FROM StockData WHERE Symbol = 'AAPL' ORDER BY Date ```

By automating the calculation of ATR in SQL, you can easily incorporate the ATR values into your analysis and trading strategies without having to manually calculate them for each symbol.

## What are some common mistakes to avoid when computing the ATR in SQL?

1. Including NULL values: Make sure to filter out or handle any NULL values in the data before computing the ATR.
2. Using incorrect date formats: Ensure that the date formats in the data match the format specified in the SQL query to avoid errors in calculating the ATR.
3. Not accounting for weekends and holidays: Consider adjusting the calculation of the ATR to account for weekends and holidays when the market is closed.
4. Using incorrect window size: Double check that the window size specified in the ATR calculation aligns with the desired time period for analysis.
5. Failing to order data properly: Ensure that the data is properly ordered by date or time before calculating the ATR to avoid incorrect results.

## How can I calculate the ATR using historical price data in SQL?

To calculate the Average True Range (ATR) using historical price data, you can use the following SQL query:

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 ``` ```WITH ATR_Data AS ( SELECT *, CASE WHEN row_number() OVER (ORDER BY date) = 1 THEN high - low ELSE GREATEST(high - low, ABS(high - lag(close, 1) OVER (ORDER BY date)), ABS(lag(close, 1) OVER (ORDER BY date) - low)) END AS TrueRange FROM YourTable ), ATR AS ( SELECT date, AVG(TrueRange) OVER (ORDER BY date ROWS BETWEEN 13 PRECEDING AND CURRENT ROW) AS ATR FROM ATR_Data ) SELECT date, ATR FROM ATR ```

In the query above, replace `YourTable` with the name of your table containing historical price data. The query calculates the True Range for each row in the dataset, then calculates the ATR as the 14-day exponential moving average of the True Range. The final result includes the date and corresponding ATR values.
